Flow Meters

Nominal diameter: DN15~1500mm (greater than 200mm for insertion structure)
Accuracy: 0.5%, 1.0%, 1.5%, 2.5%
Nominal pressure: 1.6Mpa 2.5Mpa 4.0Mpa
Medium temperature: -40~+350°C
Output signal: Voltage pulse; 4-20mA DC (two-wire system)
Power supply: 12V DC or 24V DC; 3.6v battery
Body material: 304 stainless steel
