Water Analyzers

XPHA-100 PH Controller

Measuring Range: -2.00 ~ 16.00 pH
Accuracy: ±0.01 pH
Resolution: 0.01 pH
Dimensions: (H*W*D) 96*96*113mm

Contact

Controller	Parameter
pH Measuring Range	-2.00 ~ 16.00 pH
pH Resolution	0.01 pH
pH Accuracy	±0.01 pH
ORP Measuring Range	-2000 ~ 2000 mV
ORP Resolution	1 mV
ORP Accuracy	±1 mV
Temperature Measuring Range	-10.0 ~ 130.0 ℃
Temperature Resolution	0.1 ℃
Temperature Accuracy	±0.3 ℃
Temperature Sensor	PT1000
Temperature Compensation	Automatic / Manual
Protection Grade	IP65
Installation Method	Panel Mount
Dimensions	96×96×113 mm
Cutout Size	92×92 mm
